Magnetic Scale Reducer

Warranty:
1
Years

The Fernox Magnetic Scale Reducer range is suited to single appliance protection and is most notably used to protect the boiler against the damaging effects of scale. It is easily connected onto 22 mm pipework and requires no further maintenance, while the positive effects continue for up to 10 years, dependent on water usage levels. Part L of the Building Regulations (England and Wales) states that in hard water areas which exceed 200ppm, provision should be made to treat feed water to water heaters and hot water circuits of combination boilers to reduce the rate of limescale formation as well as limiting its harmful effects on energy efficiency

  • An in-line scale reducer to prevent the build-up of scale using magnetic principles
  • Single appliance protection
  • A brass, nickel plated unit
  • Lasts for up to 10 years
  • WRAS approved product
  • No need for an earth bond strap
Available Versions
Product CodeFit Type and SizeProduct Data Sheet (PDF)
58264
Fit Type: Compression, Metric Fitting Size (mm): 15mm
62302
Fit Type: Compression, Metric Fitting Size (mm): 22mm
Application

The Fernox Magnetic Scale Reducer is installed into the pipework using compression fittings. In an average domestic household, the Fernox Magnetic Scale Reducer provides single appliance protection. The unit is effective immediately and is guaranteed for 12 months against manufacturing defects. The unit is pressure rated to 10 bar at 20˚C with an operating temperature of 2˚C to 40˚C (cold feed) and is designed for 22mm pipework. Install in compliance with WRAS installation requirements IRN R001, R120, R150, R170, R290 and/or local water regulations.

Select a straight pipe run that is long enough to position the unit, and ideally install no further than one metre before the appliance needing protection. The Fernox Magnetic Scale Reducer is designed for single appliance protection only. If protecting a boiler, install no further than one metre away.

Physical Specification / Properties

Matierial: Forged Brass, Nickel Plated

Package, Handling & Safety

The Fernox Magnetic Scale Reducer can be installed in horizontal or vertical pipework. The unit is classified as non hazardous, but magnets may affect or interfere with sensitive mechanical and electronic instruments such as heart pacemakers, computers, magnetic media and watches. Always keep magnets at least 300mm (1 foot) away from such devices. Torque compression fitting to 50Nm.

Volumetrics
Product CodeFit Type and SizeSingle Unit BarcodeSingle Unit Box Dimensions
(Depth x Width x Height)
Outer Carton Barcode (ITF)Outer Carton Box Dimensions
(Depth x Width x Height)
58264
Fit Type: Compression, Metric Fitting Size (mm): 15mm
5014551582644
40 x 185 x 40 mm
05014551000018
90 x 221 x 200 mm
62302
Fit Type: Compression, Metric Fitting Size (mm): 22mm
5014551623026
40 x 185 x 40 mm
05014551001398
90 x 221 x 200 mm
Videos
Fed up with limescale
